– BLACK POWDER COAT Hammertone as standard

– Holes are predrilled for park sensors & Suits tech pack ACC lane assist module

Product Features

INCLUDES WINCH CRADLE – Can suit upto 13,000lb Low mount Winch.


  • Made from 8mm steel main winch cradle & 3mm side wings reinforced
  • ADR69 compliant and airbag compatible Tested by ASE
  • Meets AS4876.1 2002
  • Suits most low mount winches upto 12,000LB
  • Rated tow points(3500-4000 kg each Tested) Recommended use with bridal and winch only. Snatch strap can exceed 8T total that is why recommended as a tow point Fits with Aftermarket dedicated recovery points such as roadsafe.
  • Powder coated in texture black or can be colour matched(Additional Cost)
  • bash plate back to front diff included
  • Fits factory fog lights
  • Loop does not protrude past the front of the bar
  • Can suit 9inch LED spot lights or LED bars.
  • 2x Spot light mounting points are located on the loop bar.
  • The bar can be adjusted approx 20mm from the fender or can be adjusted to sit flush.
  • Its a complete bumper replacement making install time frame 2.5-4Hr
  • Install Difficulty = Medium (Some Trimming required)


The standard colour coding is as follows.
1) Main bullbar & Loop colour matched to 4WD with black centre for 2 tone look.
2) Centre winch section Black Hammertone for durability.
3) Fog Lights – Black Hammertone for durability.
4) Bash Plate – Black Hammertone for durability.

The bulbar arrives in black hammertone standard, the bar is then sent to a sand blaster, after which its then sent to a painter, who will primer the bar, spray the bar in either waterbase paint or 2pac paint then apply a gloss/ceramic coat on top.

The process reflects our colour coding fee of $700. This includes all the transport costs, packaging costs, the sandblasting & the painting.

If you wish to order a bar in primer a $150 fee applies in which sand blaster will blast the bar only & apply powder coat primer and bake.

If you wish to have the fog lights colour matches an additional fee of $99 applies to the $700.

If you wish to powder coat your bash plate a different colour other than black ripple a $175 fee applies.

If you wish to colour match the loop on your bar a $50 fee applies.


Bullbars are delivered completely wrapped in cardboard & strapped to a pallet.
If you ordered a colour coded bullbar it will arrive in a large box strapped to a pallet.
Due to the weight its critical you are there to help unload or get delivered to business address with forklift or walkie stacker.

This process keeps any damage to nil, but if for some reason courier has damaged the bar it is your responsibility to report
the damage to the bar or box before installing the product. Shoreline 4×4 does not cover any damage or returns if you have installed
the product which you believe to be damaged by courier.
